Summary of problems with trolley series shot blasting machines

1. The vibrating conveyor screen is to match the separator screen.

2. The air inlet must be sealed with a sealing cover

3. The design of the air outlet, first of all, the opening position conforms to the principle of downward suction and upward delivery, and then the design direction and installation direction of the grille must be reasonable and free of sand.

4. The sand port and discharge port of the hoist cannot be on the same side.

5. If the pit is too deep, the screw conveyor can be added.

6. When there is a vibrating screen, pit dust removal is necessary.

7. The gate is left back to the sand tank, and the width is greater than the width of the gate.

8. When the chamber body is divided into half, there should be a margin for the guard plate at the splicing place, so that it is easy to lay the guard plate after splicing without leaving any gaps.

9. The lighting system shall adopt the latest structure for easy observation and installation.

10. The trolley must have frequency conversion for its rotation.

11. When the flat car passes through the shot blasting cleaning, when the walking adopts frequency conversion speed regulation, the constant torque reducer must be used, and the selection of the frequency converter must be reasonable and correct, that is, the electromechanical interface communication must be in place.

12. The arrangement of shot blasters must be misplaced with each other, and not centered. It is advisable to use 200-500.

    For the fracture of the axle of the platform, strict processing requirements must be imposed in the design, and heat treatment and processing technology requirements must be clearly marked or set clearly. And it is necessary to check the torque of the driving shaft to ensure that the force is controlled within a reasonable range.

13. The ladder of the large shot blasting room must be in the form of an inclined ladder and the design angle is reasonable and humanized.

14. The observation window and lighting should be designed reasonably, and the light intensity should not be greater than 300lux in theory
