Single Wire Rod Shot Blasting Machine-china shotblastingmachine Keejoo

Single Wire Rod Shot Blasting Machine

Composition and structure characteristics of equipment The machine is mainly co

Product Inquiry

Composition and structure characteristics of equipment

The machine is mainly composed of blast chamber, blast wheel, bucket elevator, screw conveyor, separation system, electrical system, dust collector etc.

	Item		Indicator
1	Blast wheel(QY-30 Inside blast wheel)		4*22Kw
2	Cleaning room		175019501725 Adopts high abrasion protection board-- rolling Mn13, including projectile,air inlet, check gate, wire rod guiding device and so on.
3	Screw conveyor		WD-21 -1385L 1.5Kw*4P gear reducer Delivery value 145t/h
4	elevator		BES-10A 3700H Adopt heat resistant belt and check gate Delivery value 145t/h
5	Separator		WE-1A Model Winnowing storage
6	Flow regulating device		4 wf-3 air control gates can be adjusted manually, with a full set of inlet pipes.
8	Dust removal pipeline		From cleaning room to dust collector with butterfly valve, cyclone settling box.
9	Dust Collector		UDC blowback type Air quantity: 60 m³/min Static pressure：3.92KPa
10	Guide		Wire inlet and outlet guide with detector.
11	Power	Total	168kW
		Total compressed air consumption	0.2-0.3 m³/min
12	Electric Control System		Working power supply 380V/50Hz，operational power supply 220V/50Hz，Siemens PLC Automatic control system, Schneider contactor, electric control box, detection mechanism, cable, wire, current instrument, bridge and so on.
13	Capability		Wire specification: W3-W40 Cleaning speed：MAÍ60-80M/min Suitable for projection materials：W0.2-1.0mm Initial input： 1500-2500Kg Through the center line height：FL+1100mm


If you have any question about shot blasting, please keep us informed.

-----KEEJOO
